RF Cable Assemblies

Cable


Assemblies

Step 01

Select Your Cable

Choose a cable from our RF cable catalog that fits your loss and heat load requirements, and decide on the cable length you need.

View Cables
Step 02

Select Connectors

Choose connectors for each end of the cable assembly. Specify if you need non-magnetic connectors. Contact us if you need a connector not listed on our connector list.

Explore Connectors
Step 03

Request a Quote

Request a quote specifying the different cable configurations you need. Tell us the quantity, cable material, length, and connectors for each cable configuration.

Request a Quote

Cable Assemblies FAQs

What connector options do you offer?
:
;

Review our connector page for a list of the connectors we offer. Please contact us if you do not see the connector you need.

What customization options are available?
:
;

We can customize the cable length and connector configurations. We can also add a non-conductive outer jacket to the cable assemblies if desired.

Is there a minimum cable length you can fabricate?
:
;

We can fabricate almost any length for any cable type except niobium-titanium. The minimum cable length for the niobium-titanium cable is about 2 inches.

Can you fabricate cables with different solder compositions?
:
;

Yes, we normally use Sn96Ag4 solder which is good for vacuum and also relatively soft, but we can also use other solder compositions such as Sn63Pb37 and Sn96.5Ag3.0Cu0.5 on request.

Can you fabricate cable assemblies with connectors that are not listed on the website?
:
;

Yes, we can fabricate cable assemblies with other connector types not listed on the website. Contact us for more information.

Are the cables ready for use in vacuum when I receive them?
:
;

Yes, we thoroughly clean and dry each cable so that it is ready for vacuum once you receive them.

What testing is standardly done on cable assemblies?
:
;

We standardly conduct continuity and high resistance short testing for the center and outer conductor of each cable assembly.

Can I request more involved testing such as S-parameter, TDR, Hi-Pot, or other tests?
:
;

Yes, we can do S-parameter, TDR, Hi-Pot and resistance testing for an additional fee.

Do you test completed cable assemblies at low temperatures?
:
;

We have in-house cryostat testing capabilities, but we currently don’t offer this testing for standard orders except for special circumstances.
